Precise Pipe Burst Testing with XGJ-25M Hydrostatic Pressure Testing Machine
Overview:
This instrument is primarily utilized in testing scenarios involving metal pipes, thermoplastic pipes, reinforced thermoplastic composite pipes, oil pipelines, hydraulic components, gas cylinders, pressure vessels, aerospace pressure pipelines and containers, engineering hydraulic hoses, and automotive hoses—specifically for ultra-high pressure resistance testing. It is also applicable to hydraulic instantaneous burst testing of high-pressure pipelines and containers.
As a critical testing instrument, it is indispensable for manufacturers, research institutions, and quality inspection authorities.
Implementation standards:
GB/T 6111-2018, GB/T 15560-95, GB/T 5351-2005, ASTM D1598-2009, ASTM D1599-2005, SY/T 7043-2016, SY/T 6662.2-2012, SY/T 6662.7-2017, SY/T 6662.8-2016, SY/T 6662.7-2016 and other standards requirements.
Pressure chart:
Product features:
-
The system adopts plunger pump + frequency converter control to enable high-pressure regulation. A 15L/min pump is deployed for rapid pressurization, ensuring that the pressurization process for samples with a pipe diameter of φ400mm and a maximum length of 1000mm can be completed within 60~70 seconds.
-
The host system utilizes a centralized cluster control architecture based on embedded PCs. Each workstation functions as an independent module integrated with microcomputers, which receive control instructions from the embedded PC, execute pressure adjustment, logic processing, and data collection. Meanwhile, these modules continuously transmit control data back to the PC through a serial bus, enabling automatic identification of sample volume characteristics and material properties.
-
The exclusive pressure control system automatically formulates pressure-rising protocols and algorithms, guaranteeing rapid pressure rise, stable constant pressure, strong expansion capability, and a 100% test success rate. It comes with functionalities including real-time monitoring, data storage, power-off data protection, power-on data recovery, test result storage and printing, and sample pre-treatment.
-
High-precision pressure acquisition and control are achieved through the adoption of a vector frequency conversion system and high-precision pressure sensors. A fuzzy PID pressure control algorithm is employed to realize linear pressure rise until burst. High-precision pressure transmitters and subsequent conditioning circuits are utilized to achieve high-precision pressure acquisition.
-
Featuring ease of use and convenient operation, the instrument is equipped with an automatic pressure relief function (only one button is required for pressure release). Two time display modes (count-up and count-down) can be switched freely, and it also supports storing and printing test reports that include curves and test data.
Technical parameters:
| 1) Test station | 1 channel, ultra-high voltage |
| 2) Maximum test pressure | 25MPa |
| 3) Maximum error | ±1% |
| 4) Sample size | Inner diameter Φ20mm~400mm, L1000mm or customer-specified |
| 5) Blasting time | 60-70s instantaneous blasting (the sample expansion is less than 15L/min) |
| 6) Test medium | water |
| 7) Power | 20kw |
Product configuration:
- Integrated Microcomputer Control System: 1 unit per module
- Embedded Industrial Control Computer: 1 set
- Pressure Control System: 1 set
- High-Pressure Plunger Pump (Brand: Bortolini): 25MPa, Flow Rate 15L/min, 1 unit
- Pressure Transmitter: 1 unit (Origin: USA, Brand: GEMS)
- PC Data Management Software: 1 set
- High-Pressure Hoses: 2 pieces
- Accessories and Documentation: 1 set
Safety of high pressure test:
- During ultra-high pressure blasting tests, test specimens shall be placed in a secure pit or a temperature-controlled medium chamber equipped with safety explosion-proof devices, so as to ensure operational safety.
- For instance, when testing pipes with a diameter of φ315mm under a pressure of 20MPa, any damage to the pipe ends or other components may result in serious hazards.
FAQ:
Q1: What is the purpose of the Hydrostatic Testing Machine (Plastic Pipe Hydrostatic Pressure Testing Machine)?
A1: The Hydrostatic Testing Machine (Plastic Pipe Hydrostatic Pressure Testing Machine) is designed to test the hydrostatic strength and bursting strength of plastic pipes.
Q2: What types of components and materials can the Hydrostatic Pressure Testing Machine test?
A2: The Hydrostatic Pressure Testing Machine is capable of testing plastic pipes and composite pipes (e.g., PP-R, PP-B, PP-A, PVC, PE, PE-X, etc.).
Q3: What is the accuracy of the Hydrostatic Pressure Testing Machine?
A3: The Hydrostatic Pressure Testing Machine features an accuracy of within 0.1% of the full-scale reading.
Q4: What is the maximum pressure that the Hydrostatic Pressure Testing Machine can handle for testing?
A4: The Hydrostatic Pressure Testing Machine supports pressure testing up to 10MPa (100 bar, 1450 psi).
